Application:-

Solventless laminator is Suitable for High-Speed Solventless adhesive lamination of different types of plastic/metalized films, paper and Aluminium Foil. This Application is most suitable for food packaging industry.

Technical Specification:-

Materials to be processed Polyester, BOPP, Aluminium Foil, LDPE/HDPE
Un-winder/Re-winder Diameter 1000 mm
Mechanical Speed 400 Mpm

General Specification:-

  • Laminating station is located on the opposite side of the gluing section. This results in their close proximity with the un-winder of the material to be laminated. This particular configuration facilitates and optimizes the lamination of delicate webs such as thin aluminum foil at high speed.

  • High precision measuring steel roller with three rollers for adhesive transfer.

  • Precision micro gap adjustment for adhesive ensures precise coating weight.

  • Back up pressure for lamination nip to ensure better performance.

  • Roller heating through water/oil heating systems.

  • High precision digital a/c vector drive.

  • All electrical and electronic components are confined inside of a cabinet which is part of the machine body for easier wiring and maintenance.

  • Very precise tension controls due to selected electronic components.

  • Shaft less un-winders and re-winder.

  • Thick stress released metal frame. CNC machined for total machine fabrication.
