Application:-

This sitter rewinder simplex /duplex surface winding machine capable of handing extensive materials with guage variations to high tensile films, specially PET, BOPP and Polythene film at specified speeds. It is designed for easy operation and minimum maintenance,

Technical Specification:-

Materials to be processed: Plain or printed films- PET, BOPP, Polyfilm & Paper, plain and printed Laminates.
Minimum Slit Width 30mm
Maximum Mechanical Speed 500 MPM
Maximum Un-Winder Diameter 1000mm
Maximum Re-winder Diamete 600mm

General Specification:-

  • A heavy duty un-winder with tracking trolly with safety chuck based air shaft mounting along with edge guiding system.

  • Also shaft-less un-winder provision is there.

  • Safety interlocks are provided in all operations sequences.

  • Razor Blade & Rotary Sitting system.

  • Heavey duty, multiple bearing supported rewind friction shaft is provided for easy and fast changeover.

  • The electrical panel will be with IP-55 protection and emergency switch will be provided on each important position.
